Database

SQL SERVER – Azure SQL Databases Backup Made Easy with SQLBackupAndFTP

Azure SQL database backup used to be a difficult task. Not any more. With SQLBackupAndFTP with Azure it became trivial. Here’s what you basically need to do:

Once  SQLBackupAndFTP with Azure  is installed, click at “Connect to SQL Server / Azure” button and specify connection properties for your Azure SQL Databases:

0236863e30 image03

Then click “Run Now” to backup your Azure SQL Database(s):

0236863e30 image00

Scheduling backups is also very simple – just check “Schedule this job on the main form” to run once daily or go to Advanced Settings for more options

3f0792d284 image04

Sounds simple? There are just a couple more things you need for this to work: you should know your Azure Server Name and Azure should allow your IP to connect. Let me explain how to do it.

How to find your Azure SQL Databases Server Name/Connection String

If you do not know a server name of Azure SQL Database, you can find this out on  Windows Azure Management site.  Sign in with your Microsoft account and click the “SQL DATABASES” menu item, then click your database name

7b659ac49b image01

Then click “Show connection strings” link in the bottom right corner:

7b659ac49b image05

You will see the connection strings for many platforms. Just copy to clipboard “Server” property value of “ADO.NET” connection like in the screenshot below:

87c6b8bc36 image06

And paste it into the “Server Name” field of the “Connect to SQL Server / Azure” window in SQLBackupAndFTP:

455b60c5eb image07

Allow your IP address to connect  to your Azure SQL Databases server

For SQLBackupAndFTP to connect to Azure SQL Database, you need to configure Azure’s firewall. Otherwise you will be getting the error: Cannot open [server] requested by the login. Client with IP address [ip-address] is not allowed to access to the server…

Login to Windows Azure Management site with your Microsoft account, click “SQL DATABASES” menu  item, then click your database:

7b659ac49b image01

Then click “Manage allowed IP addresses” link in the bottom right corner::

953fbf5d2b image02

You will see a page where you can specify an allowed IP addresses for your databases:

f2d5f687f5 image08

On this page you can configure your firewall to allow the machine where SQLBackupAndFTP is running access to Azure. After adding the proper IP you should have no problem connecting to Azure.
